APTY series (iron bottom plastic surface)

■Transparent door, made of ABS material that can be turned up 180°. ■Rated operating voltage: 230/400V AC ■Short-time withstand current: 4kA ■ Maximum operating current: 125A ■Materials 口 Panel is made of ABS material. 口Bottom of high quality cold-rolled steel(0.8, 1.0, 1.2, 1.5mmoptional), the surface through electrostatic spray, anti-corrosion effect. ■ Protection class: IP30

products detial


APTY series (iron bottom plastic surface)

The main technical parameters

■Transparent door, made of ABS material that can be turned up 180°.

■Rated operating voltage: 230/400V AC

■Short-time withstand current: 4kA

■ Maximum operating current: 125A

■Materials

■Panel is made of ABS material.

■Bottom of high quality cold-rolled steel(0.8, 1.0, 1.2, 1.5mmoptional), the surface through electrostatic spray, anti-corrosion effect.

■ Protection class: IP30

■ Installation and wiring

■Knockout holes up for easy inlet and outlet terminals

■Bottom rail between the box and the spaced rails can lift adjustment, accurate installation.

■Zero line, ground terminals, optimizing the pitch and aperture,carrying more current, wiring easier

■meet the criteria: GB72513-2006



Product Name

 Model/ Specifications

Rows

((WxHxD)MM bottom box

(WXHXD)MM Dimensions

End section Size(mm)

Unit

Number pkgs

APTY

APTY-8RT

1

211*210*90

257*260*110

7*9

Only

20

APTY-12RT

1

283*210*90

330*260*110

7*9

Only

12

APTY-16RT

1

355*210*90

400*260*110

7*9

Only

10

APTY-20RT

1

427*210*90

475*260*110

7*9

Only

8

APTY-24RT

2

283*340*90

330*385*110

7*9

Only

6

APTY-36RT

3

283*465*90

330*506*110

7*9

Only

6



Note: The median refers to a multiple of 18mm and a width of 18mm
