What we can do ? different country different requirement all we can offer.
Mid-voltage ( kV) | 3.6~35kv (E.g. 35,33,24,22,20,18,15.75,13.8,13.2,12,11,10.5,10,7.2,6.6,6.3,6 etc.) |
To Low voltage ( V) | 100-660V (E.g. 100,110,115,120,127,208,200,220,230,240,346,380,400,410,415,440,480,660 etc.) |
Frequency (HZ) | 50Hz or 60Hz |
ZW20B-12 outdoor high voltage vacuum circuit breaker
Ⅰ.Overview
The FZW20-12 outdoor pole-mounted high-voltage vacuum circuit breaker is an outdoor high-voltage switchgear with a rated voltage of 12kV and a three-phase AC 50Hz. Mainly used for breaking and closing the load current, overload current and short circuit current of the power system. It is suitable for protection and control of substations, industrial and mining enterprises and urban and rural power distribution networks, and is especially suitable for places with frequent operations and urban power distribution networks.
This product is matched with the controller, which can meet the requirements of the distribution automation system, and can reliably and effectively complete the traditional recloser function. It adopts a mature box-type sealing structure and is filled with SF6 gas. It has good sealing performance, so that it is not affected by the external environment. It is a maintenance-free product. The spring operating mechanism adopts a direct-acting chain main drive and a multi-stage tripping system, which has high operational reliability and is a good product for pole-mounted circuit breakers.
II. Model and description
FZW 20-12/T port-port
口-rated short-circuit breaking current
口-rated current
T-spring operating mechanism
11- rated voltage
21-Design serial number
W-outdoor
FZ-Vacuum Circuit Breaker
Ⅲ.Specification
No. | Name | Unit | Data |
1 | Rated voltage | Kv | 12 |
2 | Rated frequency | Hz | 50 |
3 | Rated current | A | 630 |
4 | Rated short-circuit open current | KA | 20 |
5 | Rated off current peak | KA | 50 |
6 | Rated stable current bee value | KA | 50 |
7 | 4s Thermal stable current | KA | 20 |
8 | Rated operation order | Opening-0.3s-Closing/Opening-180s-Closing/Opening | |
9 | Rated energy storage motor voltage | v | AC220 |
10 | Maximum / minimum energy storage motor voltage | v | AC242/87 |
11 | Rated closing operating voltage | v | AC220 |
12 | Maximum / minimum closing operating voltage | v | AC264/43 |
13 | Rated gate operating voltage | v | AC220 |
14 | Maximum / minimum split operating voltage | v | AC264/43 |
15 | The closing gate is not the same period | ms | ≤2 |
16 | Different period of opening | ms | ≤2 |
17 | SF6 Gas rated pressure (gauge pressure) | Mpa | 0.01 |
18 | Rated short-circuit current open open times | time | 30 |
19 | Mechanical life | time | 10000 |
