LZZBJ9-10/175b/4(s) Indoor High-Voltage Current Transformer

products detial

LZZBJ9-10/175b/4(s) Indoor High-Voltage Current Transformer

Model meaning

Technical Parameters

◆Rated insulation level: 12/42/75kV;

◆Power factor of load: COSφ=0.8 (hysteresis);

◆Rated secondary current: 5A or 1A;

◆Rated frequency: 50 or 60Hz;

◆Pollution level: Grade II ;

◆Ambient temperature: the lowest temperature is -25℃ , the highest temperature is 40℃ , and the daily average temperature is not more than 30℃ ;

◆Altitude:≤1500 meters;

◆Product standard: GB20840.1 GB20840.2.

Technical Data Sheet

Rated primary current(A)	Accurate level combination	Rated outpul(VA)			Accurate limit factor	Rated short-time thermal current(kA)	Raled dynamic current(kA)
		0.2s	0.5	10P
5-200	0.5/10P 0.5/10P/10P 0.2S/0.5 0.2S/10P 0.2S/0.5/10P/10P 0.2S/10P/10P	15	15	20	10、15 20/30	100lin	225lin
300						31.5	80
400
500						80	160
600
800
1000						80	160
1200
1500		20	20			100	160
2000
2500
