JDZ-10 Indoor High-Voltage Voltage Transformer

JDZ-10 Indoor High-Voltage Voltage Transformer

products detial


JDZ-10  Indoor High-Voltage Voltage Transformer

JDZ-10戶內(nèi)高壓電壓互感器

Model meaning

 JDZ-10戶內(nèi)高壓電壓互感器2

Technical Data Sheet

Model



Rated voltage

ratio(kV)



Accurate grade and

accurate combination

Rated output(VA)



uimit output(VA)



Rated insulation level(kV)

0.2

0.5

3

JDZ-6Q

6/0.1

0.2/0.5

0.2/0.2

0.2(0.5)/3

15

30

100

500

7.2/30/60

6/0.1/0.1

6/0.1/0.22

JDZ-10Q

10/0.1

0.2/0.5

0.2/0.2

0.2(0.5)/3

12/42/75

10/0.1/0.1

10/0.1/0.22



Model



Rated voltage ratio(kV)

Rated output(VA)



Limit output(VA)



Rated insulation level(kV)

0.2

0.5

3

3P(6P)

JDZJ-6Q

61√3/0.1/ √3/0.1/3

15

30l

60

50(100)

400

7.2/30/60

6/√3/0.1/√3/0.1/√3/0.1/3

JDZJ-10Q

10/√3/0.1/√3/0.1/3

12/42/75

10/√3/0.1/√3/0.1/√3/0.1/3

Shape and installation dimensions(mm)

JDZ-10戶內(nèi)高壓電壓互感器+

×
