What we can do ? different country different requirement all we can offer.
Mid-voltage ( kV) | 3.6~35kv (E.g. 35,33,24,22,20,18,15.75,13.8,13.2,12,11,10.5,10,7.2,6.6,6.3,6 etc.) |
To Low voltage ( V) | 100-660V (E.g. 100,110,115,120,127,208,200,220,230,240,346,380,400,410,415,440,480,660 etc.) |
Frequency (HZ) | 50Hz or 60Hz |
ZW32-12 outdoor vacuum circuit breaker
I. Overview
The ZW32-12 outdoor vacuum circuit breaker (hereinafter referred to as the circuit breaker) is an outdoor power distribution equipment with a rated voltage of 12kV and a three-phase AC 50/60Hz. Mainly used for breaking and closing the load current, overload current and short circuit current in the power system. It is suitable for protection and control in power distribution systems of substations and industrial and mining enterprises, and places where rural power grids are frequently operated.
This circuit breaker has the characteristics of small size, light weight, anti-condensation, maintenance-free, etc., and can adapt to harsher climatic conditions and dirty environments.
II. Model and description
ZW 32-12/T630-20 G-port
口-S hand exercise. D electric exercise
G-band isolation
20-Rated short-circuit breaking current (kA)
630-rated current (A)
T-Bouncing Mechanism
12-Rated voltage (kV)
32-Design serial number
ZW-Outdoor Vacuum Circuit Breaker
Ⅲ.Specification
No. | Name | Unit | Data |
1 | Rated voltage | Kv | 12 |
2 | Rated frequency | Hz | 50 |
3 | Rated current | A | 630 |
4 | Rated short-circuit open current | KA | 20 |
5 | Rated peak tolerance current (peak) | KA | 50 |
6 | Rated short-time tolerated current | KA | 20 |
7 | Rated short-circuit turn-off current (peak) | KA | 50 |
8 | Mechanical life | time | 10000 |
9 | Rated short circuit open current open times | time | 30 |
10 | Power frequency withstand voltage(1min):( Wet(Dry)Alternatively, to the ground/ fracture | KV | 42/48 |
11 | Lightning impact withstand voltage (peak) alternate、to the ground/ fracture | KV | 75/85 |
12 | Secondary circuit 1min Workfrequency pressure resistance | KV | 2 |
